Service Description for Profile Development and SIM Card Personalization

Introduction

3

Profile Development

3

Custom Profile Creation 3

Standard and Custom Profiles 3

Support for Multiple Technologies 3

SIM Card Personalization

4

Data Provisioning 4

Security Features 4

Custom Printing and Packaging 4

SIM Editor Tool

5

Graphical User Interface 5

Script Management 5

Versatility 5

Quality and Compliance

5

Workflows and Step-by-Step Processes

6

SIM Workflow - Simpler Overview

7

Conclusion

7

2/7

Smartjac provides comprehensive solutions for SIM card profile development and personalization, catering to various industries such as telecom, enterprise security, and private networks. Our services are designed to meet the specific needs of our customers, ensuring secure, efficient, and scalable solutions for both test and deployment environments.

Profile development is a critical step in creating customized SIM cards that meet the unique requirements of each customer. At Smartjac, we offer the following services:

CUSTOM PROFILE CREATION:

• ‌Requirement Gathering: We start by understanding the customer's needs and gathering all necessary requirements, including PLMN, Access technology, IMSI, Ki, and other parameters.

• Profile Configuration: Using our expertise and the customer's specifications, we develop a SIM profile that includes security features, application settings, and network configurations.

• Testing and Validation: Before deployment, we recommend the profiles are thoroughly tested in your lab or real-world environments to ensure they function correctly and securely.









  STANDARD AND CUSTOM PROFILES:

• ‌We provide both standard and custom profiles. Standard profiles are pre-configured and ready to use, while custom profiles are tailored to specific customer requirements, offering greater flexibility and functionality.









  SUPPORT FOR MULTIPLE TECHNOLOGIES:

• ‌Our profiles support a wide range of technologies, including 3G, 4G, and 5G, ensuring compatibility with current and future network standards.




  3/7

  ‌SIM CARD PERSONALIZATION

SIM card personalization involves encoding each card with unique information and security features, tailored to the customer's requirements. Smartjac offers several personalization options:

DATA PROVISIONING:

• ‌Full Provisioning: This process includes the complete personalization of SIM cards, from generating keys to loading data and setting access rights. It ensures that each card is secure and ready for deployment.

• Partial Provisioning: Customers can choose to handle sensitive data themselves. In this case, we provide partially provisioned cards along with the necessary tools and training for secure on-site completion.









  SECURITY FEATURES:

• ‌Key Management: Secure generation and handling of keys, including symmetric and asymmetric keys, are crucial for maintaining the security of SIM cards. We use advanced cryptographic methods to protect sensitive data.

• Data Encryption: All data exchanged during the personalization process is encrypted using robust encryption standards such as PGP, ensuring secure communication and data integrity.









  CUSTOM PRINTING AND PACKAGING:

• ‌Design Customization: We offer customizable printing options for SIM cards, including logos, colors, and other design elements to meet branding requirements.

• Environmentally Friendly Options: Our packaging solutions include eco-friendly materials and designs to support sustainability initiatives.




  4/7

  ‌SIM EDITOR TOOL

Smartjac’s SIM Editor is a powerful tool used globally for SIM card administration and personalization. It offers:

GRAPHICAL USER INTERFACE:

• ‌A user-friendly interface that simplifies the process of creating, managing, and executing scripts for SIM card personalization.









  SCRIPT MANAGEMENT:

• ‌The ability to create and execute complex scripts, enabling efficient management of large batches of SIM cards.









  VERSATILITY:

• ‌Support for various card types, including USIM, ISIM, and GSM, and the ability to work with 3G, 4G, and 5G UICC SIM cards.

At Smartjac, we adhere to the highest standards of quality and compliance. Our processes are designed to meet industry standards and regulatory requirements, ensuring the reliability and security of our products. We are committed to environmental sustainability and incorporate eco-friendly practices in our operations.

5/7

FULL PROVISIONING PROCESS

1. Key Ceremony:

   • Objective: Exchange symmetric or asymmetric encryption keys to ensure secure communication. PGP for example.

2. Generation of Operational Keys (OP, Transport Keys):

   • Option 2a: Decide who will generate the A4 key and OP key. OP key is required by Smartjac for OPc generation from a random K.

   • Option 2b: The customer generates a list including ICCID, IMSI, Ki, and OPc.

3. SIM Profiling & SIM Profile Content:

   • Objective: Decide on the content for the SIM profile (input file).

4. Printing Design:

   • Objective: Determine the design for printing on the SIM cards.

5. BAP Cards for Validation:

   • Objective: Create BAP (Before Approval Production) cards for customer validation.

6. Production of Cards:

   • Objective: Begin the production of cards, encompassing both provisioning and printing.

7. Shipping of Cards:

   • Objective: Ship the fully provisioned and printed cards to the customer.

8. Secure Sending of Ki/Opc List:

   • Objective: Securely send the list containing Ki/Opc (output file). Output files contain ICCID, IMSI, Ki, OPc, ADM1, ADM2, KiC, KiD, CHV, PUK generated during the SIM process and can also contain eKi and eOPc instead of Ki and OPc if A4 (transport key) was used to encrypt the Ki and OPc.

9. Import into HSS/UDM:

   • Objective: Import the output file into the Home Subscriber Server (HSS) or Unified Data Management (UDM).

PARTIAL PROVISIONING PROCESS

1. SIM Profile Content (Excluding Authentication Keys):

   • Objective: Decide on the content for the SIM profile (input file), excluding authentication keys.

2. Printing Design:

   • Objective: Determine the design for printing on the SIM cards.

3. BAP Cards for Validation:

   • Objective: Create BAP (Before Approval Production) cards for customer validation.

4. Shipping of BAP Cards and Provisioning Software:

   • Objective: Ship the BAP cards along with the provisioning software to the customer.

5. Training Session:

   • Objective: Conduct a training session to securely generate keys and provision the cards.

6. Production of Cards:

   • Objective: Begin the production of cards, including partial provisioning and printing.

7. Shipping of Cards:

   • Objective: Ship the partially provisioned and printed cards to the customer.

8. Secure Provisioning at Customer Site:

   • Objective: Securely provision Ki/Opc and generate the output file at the customer site.

9. Import into HSS/UDM:

   • Objective: Import the output file into the Home Subscriber Server (HSS) or Unified Data Management (UDM).

6/7

1. SIM Data Handling – Data Exchange:

   • Once the network operator and the SIM vendor have developed a SIM profile.

2. SIM Profile Document:

   • Document detailing the SIM profile, used to produce the SIMs.

3. Input File:

   • Contains information that automates SIM production, including transport keys to encrypt sensitive data.

4. Output Files:

   • Contains ICCID, IMSI, Ki, OPc, ADM1, ADM2, KiC, KiD, CHV, PUK generated during the SIM process.

Smartjac’s services for profile development and SIM card personalization are designed to offer flexibility, security, and efficiency. Our expertise in the field, combined with advanced tools and processes, ensures that our customers receive high-quality, customized solutions tailored to their specific needs. Whether you require a small batch for testing or a large volume for deployment, Smartjac is equipped to deliver with precision and speed.

For more information, please contact us at order@smartjac.com or visit our website at www.smartjac.com

.
